Zreyah Semiconductor Systems Pvt Ltd
Model : MY 200 LX 10
Speed : 16000 CPH
No of Machine : 1
Feeder capacity : Up-to 176
Fast set-ups and changeovers.
All-in-one platform.
High mix low/mid volume manufacturing.
Handling complex components – at higher speeds
Model : MY 300 LX 11
Speed : 16000 CPH
No of Machine : 1
Feeder capacity : Up-to 192
Fast set-ups and changeovers.
Full component range in one machine.
Capable of pin-in-paste, POP, QFN, board cavities and more.
Handling complex components – at higher speeds
Model : YSM 20
Speed : 90000 CPH PER MACHINE
No of machine : 2
Mounting Accuracy : ±0.035mm (±0.025mm) Cpk≥1.0 (3σ)
Repeatability is less than 2cpk
Printing quality similar to flag ship models, compatible with large circuit boards and a wide variety of stencil frames.
Built-in features from high-end machine models deliver high print accuracy and quality.
Multiple functions and extreme versatility all wrapped into 1 compact unit.
Support for Yamaha SMT production line network, delivers highly efficient production.
Inbuilt 2D solder paste inspection.
Model : YCP 10
No of machine : 2
Repeatability is less than 2cpk
Printing quality similar to flag ship models, compatible with large circuit boards and a wide variety of stencil frames.
Built-in features from high-end machine models deliver high print accuracy and quality.
Multiple functions and extreme versatility all wrapped into 1 compact unit.
Support for Yamaha SMT production line network, delivers highly efficient production.
Inbuilt 2D solder paste inspection
Model : NXT III / IIIc
Machine : 1
The Fuji NXT III is a modular, scalable pick-and-place machine for surface-mount technology (SMT) manufacturing. Its core specifications vary depending on its configuration with different module sizes and placement heads
Module Width : 320 mm
Feeder Slot Capacity : Up to 20 types of parts (based on 8mm tape)
Applicable PCB Size (Single Conveyor): 48 x 48 mm to 250 x 610 mm
Applicable PCB Size (Double Conveyor): 48 x 48 mm to 250 x 510 mm
Placement Capability: Supports a variety of components, from tiny 0201 (0.2 x 0.1mm) chips to large connectors.
Model : GPX-CII
Machine : 1
The term GPX-CII refers to a high-accuracy screen printer manufactured by FUJI Corporation, used in surface-mount technology (SMT) for applying solder paste or glue to printed circuit boards (PCBs). A GPX-CII machine is designed for high-quality, large-panel production.
Speed : The printer features a quick cycle time of 6.0 seconds, which includes panel loading/unloading, mark reading, and alignment.
Panel size: The machine can handle a variety of panel sizes, from a minimum of 48 x 48 mm up to a maximum of 610 x 610 mm.
Stencil cleaning: It has an automated, highly efficient stencil cleaning system that uses a combination of wet, dry, and vacuum cleaning methods.
Automation: The machine supports automated and programmable functions for cleaning, solder dispensing, and changeover processes to minimize operator labor and reduce downtime
9 Zone reflow oven
High volume production
Capable of ROHS and Non ROHS process
No of machine : 2nos
Model : Zenith Nova
No of machine : 1
Incomparable True 3D Inspection Performance
8 Projector (4 DLP Technology + 4 Moiré)
8 o 12 Mpx Camera
Powerful Side-View Camera: (Optional Solution) Zenith’s powerful side-view camera solution quickly identifies, measures, and analyzes potential defects on hidden or obscured components.
Self-Diagnosis for Optimal Performance Maintenance: Self-Diagnosis allows operators to take precautionary measures through predictive maintenance in order to reduce process interruptions, enhance equipment uptime, and ensure optimal machine performance.
AI-powered Auto Programming (KAP): reduces the programming process to minimizes time to production and reduces costs
Model : BX -12
No of machine : 1
Benchtop Automated Optical Inspection (AOI) System with High Resolution
Adjustable PCB fixture w/YES Clamp and camera indexing head
Full defect coverage for PCB's up to 18"x20"
Advanced Image Processing Technology
Yesvision PCM Inspection Software
3D Fusion Lighting
5 Megapixel CCD camera
Windows XP Pro Operating System
22" Flat Panel display
Model : EM-5700N Elite
No of machine : 1
High speed cutting accuracy & positioning repeatability.
High power spindle servo motor for routing of FR4 as well Aluminum and other metal clad PCBAs.
High profile CCD camera ensures better cutting accuracy.
High power suction with low noise level.
Ideal for routing of circular arc, linear or any other odd shape PCBA panels.
Ergonomic design, robust and rugged in construction and most user friendly
Model : JewelBox-100T
No of machine : 1
Anode voltage: 100 kV, 5 micron focal spot x-ray tube
Focal spot to image plane distance: 9-12″ (228.6mm – 304.8mm) (factory preset)
Outside dimensions: 35 1/8″W x 43 1/8″D x 74″H (892.175mm L x 1095.375mm W x 1879.6mm H)
Applications: Multilayer and assembled pc boards including BGA, QFN, LED and other device
Failure Analysis
IC Packaging and Wire Bonds
Model : RTX113HV
No of machine :1
Model : DH- A3
No of machine :1
Model : ZM-R7850A
No of machine : 1
Multifunctional Control Features
Convenient Temperature Setting and Saving
Bottom Heating System
Smoke Purification System
HD Optical Alignment Module
PCB Size-635*520mm(Max);6*6mm(Min)
BGA Chip Size-80*80mm(Max);2*2mm(Min)
Model : LEELASONIC-500
No of machine : 1
Drying Machine Model : Kenton 101-ZAS
No of machine : 1
Dry Cabinet Model : A1B-600
No of machine : 1
